• Wheels, 19.5" x 6.75", steel, Black painted, 8-holes, hub piloted
• Tires, front 225/70R19.5G highway blackwall Goodyear Max Axle Load: 7,940 lbs. (Requires (YAL) Tires, rear 225/70R19.5G highway blackwall Goodyear, Max Axle Load: 15,000 lbs. or (YMF) Tires, rear 225/70R19.5G traction blackwall Goodyear, Max Axle Load: 15,000 lbs.)
• Tires, rear 225/70R19.5G highway blackwall Goodyear Max Axle Load: 15,000 lbs.
• Spare tire delete
• Wheel, spare delete
• Bumper, front, Black
• Assist steps
• Front fender extension, mold-in-color Black (Not available with (FNP) Body color front fender extension.)
• Grille, base, molded in color, Black
• Grille guard screen, insect protection (mounted behind grille)
• Headlamps, halogen projector-beam
• Lamps, cargo area, cab mounted with switch on center switch bank
• Lamps, Smoked Amber roof marker
• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Mirrors, outside high-visibility vertical camper-style, Black with manual folding and extension and lower convex spotter glass
• Glass, solar absorbing, tinted
• Antenna, fixed mast
• Door handles, Black

• Audio system, 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (Requires (AE7) front 40/20/40 split-bench seat. Not available with (UE1) OnStar or (U2K) SiriusXM Radio.)
• SiriusXM, delete
• 6-speaker audio system

• Seats, front 40/20/40 split-bench, 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar.
• Air conditioning, single-zone
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Seat trim, Vinyl
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
• Seat Belt, Black
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Steering column, manual Tilt-Wheel
• Speedometer, miles/kilometers
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information
• Windows, power with driver express up and down and express down on all other windows
• Door locks, power
• Cruise control, steering wheel-mounted
• Mirror, inside rearview manual day/night
• Visors, driver and front passenger, vinyl
• Assist handle, front passenger and driver on A-pillars

• Brake, parking, driveline park brake system
• Traction control
• Daytime Running Lamps, with automatic exterior lamp control
• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• OnStar, delete
• Horn, single-note

MIRRORS, OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING, UPPER GLASS, MANUAL-FOLDING AND EXTENDING, BLACK.

• Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp

ENGINE, DURAMAX 6.6L TURBO-DIESEL V8, B20-DIESEL COMPATIBLE

• 350 hp @ 2700 rpm
• 700 lb-ft torque @ 1600 rpm (STD)

AUDIO SYSTEM, 7" DIAGONAL COLOR TOUCH-SCREEN WITH CHEVROLET INFOTAINMENT

• AM/FM stereo with seek-and-scan and digital clock
• includes Bluetooth® streaming audio for music and select phones.

TIRES, REAR 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR

• Max Axle Load: 15
• 000 lbs. (STD)

WORK TRUCK PREFERRED EQUIPMENT GROUP

• includes standard equipment

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER

• driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)

POWER TAKE OFF, ENGINE CONTROL PROVISIONS

• Access is available on left hand and right hand side

WHEELS, 19.5" X 6.75", ALUMINUM, 8-HOLES, HUB PILOTED

• Dura-Bright finish is on the outside of the wheel

TIRES, FRONT 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR

• Max Axle Load: 7
• 940 lbs. (STD)

SPARE TIRE DELETE

• (STD)

REAR AXLE, 4.30 RATIO

• Max road speed: 75 MPH

RUGGED DUTY SERVICE TRANSMISSION, AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE, ALLISON, A1750RDS

• ratios 3.10 1ST
• 1.80 2ND
• 1.40 3RD
• 1.00 4TH
• 0.70 5TH
• 0.61 Rugged Duty Series
• 19.5K GVW & 37K GCW Max.

ELECTRICAL PROVISIONS, REAR OF FRAME, UPFITTER, BODY BUILDER WIRING

• includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn

AIR CONDITIONING, SINGLE-ZONE

• (STD)

• DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS VINYL SEAT TRIM
• GLASS DEEP-TINTED
• ASSIST STEPS ALUMINUM
• MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING UPPER GLASS MANUAL-FOLDING AND EXTENDING BLACK. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
• SKID PLATE STEEL FRAME-MOUNTED PROTECTS THE TRANSFER CASE FROM THE GROUND
• ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE 350 hp @ 2700 rpm 700 lb-ft torque @ 1600 rpm (STD)
• GRILLE CHROME
• FRONT AXLE 7 500 LBS. DANA SPICER 60-256 SINGLE-REDUCTION FRONT DRIVING
• BUMPER FRONT CHROME
• AUDIO SYSTEM 7 DIAGONAL COLOR TOUCH-SCREEN WITH CHEVROLET INFOTAINMENT AM/FM stereo with seek-and-scan and digital clock includes Bluetooth® streaming audio for music and select phones.
• TRAILER BRAKE CONTROLLER INTEGRATED
• TIRES REAR 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR Max Axle Load: 15 000 lbs. (STD)
• LICENSE PLATE KIT FRONT
• GVWR 19 500 LBS. (8845 KG)
• POWER OUTLET 110-VOLT AC
• REMOTE KEYLESS ENTRY
• WORK TRUCK PREFERRED EQUIPMENT GROUP includes standard equipment
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
• POWER TAKE OFF ENGINE CONTROL PROVISIONS Access is available on left hand and right hand side
• WHEELBASE 199 (505.5 CM) 84 CA
• REAR VISION CAMERA DISPLAY INTEGRATED INTO RADIO
• TRAILERING PROVISIONS TRAILERING WIRE HARNESS ONLY TRAILER COMBINED (STOP/TAIL/TURN) CONNECTION SOCKET AND HARNESS MOUNTED AT REAR OF FRAME.
• 34 000 LBS. GCWR (15 422 KG)
• WHEELS 19.5 X 6.75 ALUMINUM 8-HOLES HUB PILOTED Dura-Bright finish is on the outside of the wheel
• TIRES FRONT 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR Max Axle Load: 7 940 lbs. (STD)
• SPARE TIRE DELETE (STD)
• RED HOT
• REAR AXLE 4.30 RATIO Max road speed: 75 MPH
• RUGGED DUTY SERVICE TRANSMISSION AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE ALLISON A1750RDS ratios 3.10 1ST 1.80 2ND 1.40 3RD 1.00 4TH 0.70 5TH 0.61 Rugged Duty Series 19.5K GVW & 37K GCW Max.
• FRONT FENDER EXTENSION PAINTED BODY COLOR
• PAINT SOLID
• ELECTRICAL PROVISIONS REAR OF FRAME UPFITTER BODY BUILDER WIRING includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
• 5500 HD SERIES
• REAR AXLE 15 000 LBS. (6 804 KG) DANA SPICER S16-130 SINGLE REDUCTION
• FOG LAMPS FRONT HALOGEN
• AIR CONDITIONING SINGLE-ZONE (STD)
• EXHAUST BRAKE
• REAR SUSPENSION 15 500 LBS. (7 031 KG) MULTI-LEAF VARI-RATE
• Turbocharged
• Locking/Limited Slip Differential
• Four Wheel Drive
• Power Steering
• ABS
• Tires - Front All-Season
• Tires - Rear All-Season
• Running Boards/Side Steps
• AM/FM Stereo
• MP3 Capability
• Auxiliary Audio Input
• Split Bench Seat
• A/C
• Vinyl Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Power Windows
• Power Door Locks
• Cruise Control
• Traction Control
• Daytime Running Lights
• Automatic Headlights
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag On/Off Switch

• Vehicle
• Number of Passenger Doors: 4
• Front Frame Rating: - TBD -
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 1100
• Cold Cranking Amps @ 0° F (2nd): 1100
• Maximum Alternator Capacity (amps): 150
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 48
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 7500
• Gross Axle Wt Rating - Rear (lbs): 15000
• Gross Axle Wt Rating - Rear (lbs): 11000
• Curb Weight - Front (lbs): 5649
• Curb Weight - Front (lbs): 5564
• Curb Weight - Rear (lbs): 3272
• Curb Weight - Rear (lbs): 3243
• Curb Weight - Rear (lbs): 3279
• Curb Weight - Rear (lbs): 3250
• Gross Vehicle Weight Rating Cap (lbs): 19500
• Gross Vehicle Weight Rating Cap (lbs): 16500
• Gross Combined Wt Rating (lbs): 34000
• Gross Combined Wt Rating (lbs): 26000
• Suspension
• Suspension Type - Front: Multi-Leaf
• Suspension Type - Rear: Multi-Leaf
• Spring Capacity - Front (lbs): 7500
• Spring Capacity - Rear (lbs): 15500
• Spring Capacity - Rear (lbs): 11000
• Axle Type - Front: Single-reduction
• Axle Type - Rear: Single-reduction
• Axle Capacity - Front (lbs): 7500
• Axle Capacity - Rear (lbs): 15000
• Axle Capacity - Rear (lbs): 11000
• Axle Ratio (:1) - Front: 4.30
• Axle Ratio (:1) - Rear: 4.30
• Shock Absorber Diameter - Front (mm): 51
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 15.375 x 1.625
• Rear Brake Rotor Diam x Thickness (in): 15.375 x 1.625
• Tires
• Front Tire Order Code: XDK
• Rear Tire Order Code: YAL
• Front Tire Size: 225/70R19.5G
• Rear Tire Size: 225/70R19.5G
• Front Tire Capacity (lbs): 7940
• Rear Tire Capacity (lbs): 15000
• Revolutions/Mile @ 45 mph - Front: 640
• Revolutions/Mile @ 45 mph - Rear: 640
• Number Of Tires Front: 2
• Number Of Tires Rear: 4
• Number Of Tires Spare: 0
• Wheels
• Front Wheel Size (in): 19.5 x 6.75
• Rear Wheel Size (in): 19.5 x 6.75
• Front Wheel Offset (mm): - TBD -
• Rear Wheel Offset (mm): - TBD -
• # of Bolt Holes - Front: 8
• # of Bolt Holes - Rear: 8
• Front Wheel Material: Aluminum
• Front Wheel Material: Steel
• Rear Wheel Material: Aluminum
• Rear Wheel Material: Steel
• Front Bolt Pattern: 8 hole JIS 10.83"
• Rear Bolt Pattern: 8 hole JIS 10.83"
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 16.6
• Steering Ratio (:1), At Lock: 19.6
• Turning Diameter - Curb to Curb (ft): 61.5
• Turning Diameter - Curb to Curb (ft): 54.8
• Turning Diameter - Wall to Wall (ft): 63.1
• Turning Diameter - Wall to Wall (ft): 56.4
• Frame
• Frame Type: High Strength Low Alloy Steel
• Sect Modulus Rails Only (in³): 8.08 Front/10.93 Belly/8.47 Rear
• Frame RBM (N/A): 404000 Front/546500 Belly/423500 Rear
• Frame Strength (lbs): 50000
• Frame Thickness (in): 0.3125
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 40
• Fuel Tank Location: Behind Rear Axle
• Exterior Dimensions
• Wheelbase (in): 199
• Wheelbase (in): 175
• Length, Overall (in): 282.8
• Length, Overall (in): 258.5
• Width, Max w/o mirrors (in): 84
• Height, Overall (in): 89.8
• Overhang, Front (in): 34.3
• Overhang, Rear w/o bumper (in): 49
• Front Bumper to Back of Cab (in): 149.48
• Cab to Axle (in): 84.09
• Cab to Axle (in): 60.08
• Cab to End of Frame (in): 133.3
• Cab to End of Frame (in): 109.0
• Ground to Top of Load Floor (in): 32.0 front/34.6 rear
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): 34.1
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 42.8
• Front Leg Room (in): 45.28
• Front Shoulder Room (in): 64.84
• Front Hip Room (in): 60.75
• Second Head Room (in): 40.51
• Second Leg Room (in): 40.94
• Second Shoulder Room (in): 64.33
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: Chevrolet Silverado MD
• Body Style: Crew Cab Chassis Cab
• Medium Duty Performance
• Driver Ratio: 1
• Torque @ Clutch Engage (ft-lbs): - TBD -
• Torque Converter: 1.764
• Static Loaded Radius (in): 15
• Max Speed For Gradeability: 75
